high output voltage: DC 1000 V
- UTD test under voltage: DC 1000 V
- insulation resistance (PV+IR): 4000 MΩ
- voltage measurement: 1000 V DC & 600 V AC
- automatic discharge
- step voltage
- measuring time
- comparison function (IR)
- high voltage alarm
- data communication: USB cable + Bluetooth application
- Lithium battery
- analog bargraph
- high-quality backlit display
- portable and convenient
- certification: CE, cETLus


Technical parameters:

- measurement of photovoltaic insulation resistance (PV)
- conventional measurement of insulation resistance
- AC/DC voltage testing (VDC/VAC)
- insulation resistance range: 0.125 MΩ - 4000 MΩ
- nominal voltage for conventional output (Conventional insulation resistance: 4 positions): 125 V, 250 V, 500 V, 1000 V
- rated voltage for PV power (photovoltaic insulation resistance: 2 positions): 500 V, 1000 V
- short circuit current: <1.5 mA
- step of each range: 10% of nominal voltage
- specifications for conventional measurement of insulation resistance and photovoltaic (PV) insulation resistance: see datasheet

- comparative measurement of insulation resistance (COMP)
- timed insulation resistance measurement (TIME)
- external voltage detection function, which enables automatic monitoring of the voltage of the measured object under voltage
- designed with a timer to automatically record the testing time
- automatic discharge and high voltage warning
- analog bar graph to display the range of insulation resistance test results
- manual / automatic shutdown
- capable of storing 1000 sets of data
- function of saving / deleting data
- data recording function
- bluetooth application
- manual / automatic backlighting
- mute function
- segmented LCD display with high resolution
- power supply: AA alkaline batteries x 6
- dimensions: 161 x 117.3 x 63 mm
- weight: 0.5 kg


Accessories :
- test leads
- test probes with flashlight:
- alligator clips:
- MC4 connectors: 1 pair
- type C cable
- carrying strap
- alkaline batteries LR6 AA: 6 pcs
